Re: Server converted power supplys.

Postby sureshot » 31 Jul 2016, 21:18

Admiral wrote:If you jump multiple outputs together, and then tinker with jumper wires and stuff to trick it into giving 13.8v, are you in any way compromising it's protection systems? If a switching unit goes nuts and starts pumping excessive voltage into your £500 radio even for a few seconds then it could be a false economy.

Not impossible to get a fault with over voltage, but highly unlikley. I've been faffing about with converted smps atx mainly, but server units and even game console psu's... i'm yet to see an over voltage problem. If anything these things are over protected, I've had a retail linear dump 19 Volts into a radio, it died, I know why, bad design. I've really given these things some stick. Its never gone over voltage, I think there hard to kill as well, simply because they designed to sniff out fault situations if they where to accure. In short i'm certain there safe. If you really wanted to add an aditional crowbar you could, but its not really necessary.
CB call. Shipwreck.

User avatar
Admiral
Legend
Legend
Posts: 8192
Joined: 08 Mar 2011, 21:20
Call Sign: 26TM157
Location: NORTH CAMBS UK

Re: Server converted power supplys.

Postby Admiral » 31 Jul 2016, 21:24

Do these PSU units do all of the clever sensing for voltage irregularities or does the smart equipment they were designed for play any part in the monitoring of them? Obviously a radio isn't quite as smart as a server unit.

These are genuine questions by the way, not some form of argument as I have never used one of these beasties, I have an old school 50amp linear unit but it's the size of a Volkswagen.

User avatar
sureshot
Veteran
Veteran
Posts: 2500
Joined: 24 Jan 2012, 21:26
Call Sign: 26TM413
Location: South East Coast UK.

Re: Server converted power supplys.

Postby sureshot » 31 Jul 2016, 22:41

To the best of my knowledge some will and do need feedback from there host device they are powering. This is why we trick them into thinking there in there intended environment, its not always perfect, but we try and get as close as possible to getting the best most stable voltage for loads possible. Some units won't play ball no matter how hard you try.

Its unkown territory, unless someone out there has trodden the path before (like the RC forum guys) the biggest user of these things. The single biggest fear for me, and others trying new units is what's been said many times before....Electrical noise on the output. If we get a quiet supply its a big bonus. I'm not going to pretend these things won't make noise, because they can, and badly in the worst units. But having said that its possible to find high quality units that put out no more than a few tens of millivolts noise, and this is well with in usable noise limits. RF gear is by its nature is fussy about its power source, but there are many units that can be used with no problems. A lot of the new psu's sold by radio retail traders are smps, but these are very good quality units, finding server or atx units with as good noise propertys is not easy. But not impossible, I don't have half the kit I could do with for noise testing, but do the best with what I've got. Some hours connection to lighting, halogen typically for testing stability, then connection to a none critical radio for some real time use normally determines if there exeptable for radio use. After a few overs with other stations you get some idea if the unit gets a green or red light. Ideally I would like to do testing under various loads whilst monitoring noise with a scope. But I can't take it that far at the moment sadly.

Maybe someone else can take up that challenge before me ! But back to your question, what where trying to do is not perfect far from it, but we try to get as close as possible, and it is trial and error stuff, only time and use of a unit says if its any good for radio use.
CB call. Shipwreck.

sec1223
Top Poster
Top Poster
Posts: 1629
Joined: 28 May 2010, 09:28
Location: west yorkshire

Re: Server converted power supplys.

Postby sec1223 » 01 Aug 2016, 14:04

valid question admiral but like sure said, these arnt just normal psu's, these are over engineered and probably had more gone into its design that most hf sets !...

iv used mine for a while now and had good results with it.. this latest one is smaller and better with higher voltage and for the price i paid, you cant go wrong..

you'l actually find that a lot of the RC guys use these (in a double config to give 24v) for charging li-on batteries and they are very very popular.

give one a go and load it up with a few 55w halogen bulbs to see how it lies regarding stability and performance.
cant stand IGNORANT b******ds

User avatar
Admiral
Legend
Legend
Posts: 8192
Joined: 08 Mar 2011, 21:20
Call Sign: 26TM157
Location: NORTH CAMBS UK

Re: Server converted power supplys.

Postby Admiral » 01 Aug 2016, 14:47

I think I just might, it sounds a bit poncy, but I struggle to lift my PSU about these days as it's so damn big and heavy, I only need 30-35amps at home so may give one of these things a go if you lot haven't bought them all.
Cheers for the info, I'll have a read through the whole thread when I get a spare hour or two.

sec1223
Top Poster
Top Poster
Posts: 1629
Joined: 28 May 2010, 09:28
Location: west yorkshire

Re: Server converted power supplys.

Postby sec1223 » 01 Aug 2016, 15:06

il sell you a converted one ! lol
cant stand IGNORANT b******ds

User avatar
Buick Mackane
Legend
Legend
Posts: 5302
Joined: 21 Aug 2012, 17:30
Location: A Country Called Scotland

Re: Server converted power supplys.

Postby Buick Mackane » 01 Aug 2016, 15:09

Admiral wrote: it sounds a bit poncy, but I struggle to lift my PSU about these days as it's so damn big and heavy, .



I pity the fool who can't lift his own PSU, Man up sukka, And dont go giving me any that jibberjabba.

I know nothing about CB Radios, I joined transmission1 thinking i would get advice on how to fix my hillman imps faulty gearbox.

sec1223
Top Poster
Top Poster
Posts: 1629
Joined: 28 May 2010, 09:28
Location: west yorkshire

Re: Server converted power supplys.

Postby sec1223 » 01 Aug 2016, 15:19

i nearly bought a mil spec psu but it weighed 48 kilo's so i didnt bother
cant stand IGNORANT b******ds

User avatar
Admiral
Legend
Legend
Posts: 8192
Joined: 08 Mar 2011, 21:20
Call Sign: 26TM157
Location: NORTH CAMBS UK

Re: Server converted power supplys.

Postby Admiral » 01 Aug 2016, 15:27

sec1223 wrote:il sell you a converted one ! lol


I'll happily buy a converted one that does 50amps if the price is right, saves me blowing myself up.

sec1223
Top Poster
Top Poster
Posts: 1629
Joined: 28 May 2010, 09:28
Location: west yorkshire

Re: Server converted power supplys.

Postby sec1223 » 01 Aug 2016, 15:37

PM sent .
cant stand IGNORANT b******ds

User avatar
sureshot
Veteran
Veteran
Posts: 2500
Joined: 24 Jan 2012, 21:26
Call Sign: 26TM413
Location: South East Coast UK.

Re: Server converted power supplys.

Postby sureshot » 03 Aug 2016, 01:36

Found this whilst looking into. Sec 1223's conversion. Might try this one as well soon. http://pa0fri.home.xs4all.nl/Diversen/D ... %20eng.htm
CB call. Shipwreck.

sec1223
Top Poster
Top Poster
Posts: 1629
Joined: 28 May 2010, 09:28
Location: west yorkshire

Re: Server converted power supplys.

Postby sec1223 » 03 Aug 2016, 08:06

sureshot wrote:Found this whilst looking into. Sec 1223's conversion. Might try this one as well soon. http://pa0fri.home.xs4all.nl/Diversen/D ... %20eng.htm


looks good..

" the PCB has a conductive intermediate layer of the same polarity.".. so to me, that means that i can drill through the pcb to attach terminals.
cant stand IGNORANT b******ds

User avatar
sureshot
Veteran
Veteran
Posts: 2500
Joined: 24 Jan 2012, 21:26
Call Sign: 26TM413
Location: South East Coast UK.

Re: Server converted power supplys.

Postby sureshot » 03 Aug 2016, 09:35

sec1223 wrote:
sureshot wrote:Found this whilst looking into. Sec 1223's conversion. Might try this one as well soon. http://pa0fri.home.xs4all.nl/Diversen/D ... %20eng.htm


looks good..

" the PCB has a conductive intermediate layer of the same polarity.".. so to me, that means that i can drill through the pcb to attach terminals.

Yes makes fiting terminal and binding posts easy if you can drill through the blade interface.
CB call. Shipwreck.

sec1223
Top Poster
Top Poster
Posts: 1629
Joined: 28 May 2010, 09:28
Location: west yorkshire

Re: Server converted power supplys.

Postby sec1223 » 03 Aug 2016, 17:24

look what iv just got in very cheap as a donor case !... i can fit 2 SPSU's in there with room to spare lol
You do not have the required permissions to view the files attached to this post.
cant stand IGNORANT b******ds

User avatar
sureshot
Veteran
Veteran
Posts: 2500
Joined: 24 Jan 2012, 21:26
Call Sign: 26TM413
Location: South East Coast UK.

Re: Server converted power supplys.

Postby sureshot » 03 Aug 2016, 20:32

If it where mine i'd put the most stable high current unit I had in that case ! Nice score there sec.
CB call. Shipwreck.
